Commissioning
28 © SICK AG • Subject to change without notice • 8014868/YIF1/2020-10-19
8 Commissioning
Pushbutton damage
IMPORTANT!
Pushbutton damage due to improper handling!
Improper handling of the pushbuttons can damage them.
This will make operation dicult or impossible. Damage
may negatively aect the enclosure rating.
For this reason:
• Operate the pushbuttons only with your ngers or a
suitable aid.
• Do not operate the pushbuttons using sharp or hard
objects.
→ For an overview of the various setup options, see Chapter 15 on page
65
8.1 Performing teach-in
NOTE!
Teach mode automatically ends if no pushbuttons have
been pushed for 5 minutes.
NOTE!
For the DT35 and DL35 distance sensors, for the Q2 out-
put, you can select a current, voltage, or switching output.
The correct output must be selected before performing
the teach procedure. → See Chapter 8.5 on page 36
NOTE!
The hysteresis is preset to 25 mm and can be adjusted
only via IO-Link.
