Technical data
60 © SICK AG • Subject to change without notice • 8014868/YIF1/2020-10-19
13.5 Inputs
Multifunction input MF
1)
1 x
→ See Chapter 8.5 on page 36
1) Response time: ≤ 60 ms
Table 26: Inputs
13.6 Outputs
Switching output
1), 2)
• DT35-Bxxxxx, DL35-Bxxxxx:
1 x / 1 x / 2 x push-pull: PNP/NPN (100 mA), IO-Link
3)
• DR35-Bxxxxx, DS35-Bxxxxx:
2 x push-pull: PNP/NPN (100 mA), IO-Link
Hysteresis
4)
• DT35-Bxxxxx, DS35-Bxxxxxx: 0 mm … 11,950 mm
• DL35-Bxxxxx, DR35-Bxxxxxx: 0 mm … 34,950 mm
Analog output
only DT35-Bxxxxx, DL35-Bxxxxx
3)
1 x 4 mA … 20 mA (≤ 450 Ω) / 1 x 0 V … 10 V (≥ 50 kΩ) / –
Analog output resolution
DT35-Bxxxxx, DL35-Bxxxxx only
12 bit
1) Output Q, short-circuit protected
2) Voltage drop < 3 V
3) Output Q2 adaptable: 4 mA … 20 mA / 0 V … 10 V / switching output
4) Congurable via IO-Link
Table 27: Outputs – sensors with switching outputs
13.7 Interfaces
Data interface IO-Link
Table 28: Interfaces
13.8 Ambient data
Protection class III
Ambient temperature range
1)
–30 °C … +55 °C
Storage temperature range –40 °C … +75 °C
Vibration resistance EN 60068-2-6 / EN 60068-2-64
Shock resistance EN 60068-2-27
Enclosure rating IP 65, IP 67
Typical ambient light immunity 40 klx
1) U
V
≤ 24 V
Table 29: Ambient conditions
