SICK RAY26 User Manual

11 Technical data
11.1 Electrical and mechanical data
RAY26P-xxxxx1 RAY26P-xxxxx3 RAY26P-xxxxx5 RAY26P-xxxxx9 RAY26P-xxxxxA
Sensing range max.
(with reflector PL80A)
0 ... 1.5 m 0 ... 4.5 m 0 ... 3 m 0 ... 4.5 m 0 ... 4.5 m
Light band dimen‐
sions / distance
approx.
24 mm x 9 mm (1
m)
55 mm x 9 mm (1m)
Minimum detectable
object (MDO)
≥ 1 mm ≥ 3 mm, 5 mm or
10 mm
1)
≥ 5 mm ≥ 10 mm ≥ 10 mm, 15 mm,
20 mm, 25 mm or
30 mm
2)
Minimum distance
between sensor and
reflector
0 mm
Supply voltage U
B
10 ... 30 V DC
Current consumption ≤ 25 mA
3)
, < 50 mA
4)
Output current I
max.
≤ 100 mA
Communication mode COM2
IO-Link 1.1
Max. response time ≤ 3 ms
5)
≤ 500 μs
5)
Switching frequency 170 Hz
6)
1000 Hz
6)
Enclosure rating IP66, IP67
Protection class III
Circuit protection A, B, C, D
7)
Ambient operating tem‐
perature
–40 °C ... +60 °C
8)9)
1)
RAY26P-xxxxx3: sensing range depends on the selected MDO (selectable via IO-Link):
3 mm = 0 ... 2 m
5 mm = 0 ... 3 m
10 mm = 0 ... 4.5 m
2)
Factory setting see data sheet, MDO is selectable via IO-Link
3)
16 VDC to 30 VDC, without load
4)
10 VDC to 16 VDC, without load
5)
Signal transit time with resistive load in switching mode. Deviating values possible in COM2 mode.
6)
With a light/dark ratio of 1:1 in switching mode. Deviating values possible in IO-Link mode.
7)
A = U
B
-connections reverse polarity protected
B = inputs and output reverse-polarity protected
C = Interference suppression
D = outputs overcurrent and short-circuit protected
8)
Avoid condensation on the front screen of the sensor and on the reflector.
9)
Allowed temperature change after Teach +/- 20 K
TECHNICAL DATA 11
8022178.18JF 02.07.2020 | SICK
Subject to change without notice
17
