Description
30/121 Revision 05 • INSTALLATION AND OPERATING INSTRUCTIONS • 8DJH • 500-8067.9
Closing time The interval of time between the initiation (command) of the closing operation and the
instant when the contacts touch in all poles.
Opening time The interval of time between the initiation (command) of the opening operation and the
instant when the contacts separate in all poles.
Arcing time The interval of time from the first initiation of an arc and the instant of final arc extinction in
all poles.
Break time The interval of time between the initiation (command) of the opening operation and the
instant of final arc extinction in the last-pole-to-clear (=opening time and arcing time).
Close-open contact time The interval of time - in a make-break operating cycle - between the instant when the contacts
touch in the first pole in the closing process, and the instant when the contacts separate in all
poles in the subsequent opening process.
Motor operating
mechanism
Power consumption of circuit-breaker motor operating mechanism
Rated current for the motor protection equipment
1
The supply voltage may deviate from the rated supply voltage specified in the table by
max. -15% to +10%.
Breaking capacity of auxiliary switch 3SV92
Closing solenoid (-Y9) The closing solenoid closes the circuit-breaker electrically. The closing command is executed
by application of an auxiliary voltage (AC or DC, depending on the design option). After
closing, the closing solenoid is de-energized internally.
OPEN 1st shunt release (-Y1) ms < 40
Additional
release
2nd shunt release (-Y3) ms < 40
C.t.-operated release (-Y6) ms < 20
Undervoltage release (-Y7) ms < 20
Low-energy release (-Y6) ms < 20
1
For operation of the switchgear beyond the range defined by IEC 60721-3-3 Class 3K4,
a minimum command duration of 100 ms is recommended.
Designation Component (item designation) Unit Time
Type 2
Circuit-breaker Max. power consumption
DC AC
Type 2 approx. 80 W approx. 80 VA
Rated supply voltage
[V]
Recommended rated current for the protection equipment
[A]
Circuit-breaker type 2
DC 24 8
DC 48 6
DC 60 4
DC/AC 110 (50/60 Hz) 2
DC 220 / AC 230 (50/60 Hz) 1.6
1 M.c.b. with C-characteristic
Breaking capacity Operating voltage [V] Normal current [A]
AC 40 Hz to 60 Hz up to 230 10
Resistive load Inductive load
DC 24 10 10
48 10 9
6097
110 5 4
220 2.5 2
