500-8067.9 • INSTALLATION AND OPERATING INSTRUCTIONS • 8DJH • Revision 05 51/121
Installation
12 Switchgear installation
12.1 Tools and auxiliary means
• Standard tools such as torque wrenches (6...50 Nm), various screwdrivers (slot, Philips and
Torx), various wrenches
• Shims with a thickness of 0.5... 1 mm to compensate floor unevenness
12.2 Cleaning agents and cleaning aids
12.3 Mounting paste
Use mounting paste only according to the installation instructions. Use only the supplied or
released mounting paste.
ATTENTION
During metal working, please ensure the following:
➭ Do not drill into the vessel.
➭ Do not leave any metal cuttings on the vessel in order to avoid rust layers.
DANGER
For protection of personnel and environment:
➭ Read the instructions for use of cleaning agents and aids carefully.
➭ Observe the warnings of the cleaning agents.
Activity Cleaning agents or aids
Cleaning the front covers, cast-resin
components, instrument transformers
Mild, customary household cleaner for general degreasing
work and cleaning work (solvent-free)
Cleaning electrostatically stressed insulation (e.g.
epoxy resin)
Dry wiping cloths; plastic cleaner containing alcohol if there is
a lot of dirt
Applying and wiping off liquid cleaning agent
(single use)
Lint-free cleaning paper
Removing dust Brush
Damp cleaning, drying Lint-free wiping cloths
Suction of drilling chips, construction waste, dust Vacuum cleaner
