500-8067.9 • INSTALLATION AND OPERATING INSTRUCTIONS • 8DJH • Revision 05 9/121

Description

6 Panel versions

Panel blocks Panel blocks can be operated with up to 4 functions in one common switchgear vessel.

Combinations of transformer feeder and circuit-breaker feeder are possible via panel

extensions.

Panel type (function) Panel width [mm]

Standard Option

R Ring-main panel 310 –

K Cable panel 310 430

T Transformer panel 430 –

L Circuit-breaker panel 430 –

Block of 2 panels Block of 3 panels Block of 4 panels

Panel

types

Block width Panel

types

Block width Panel

types

Block width Panel

types

Block width

RR 620 mm RRR 930 mm RRRR 1240 mm RRLL 1480 mm

RK 620 mm RRT 1050 mm RRRT 1360 mm RTRT 1480 mm

KR 620 mm RTR 1050 mm RRRL 1360 mm TRTR 1480 mm

RT 740 mm RRL 1050 mm RRTR 1360 mm RLRL 1480 mm

RL 740 mm RLR 1050 mm RTRR 1360 mm LRLR 1480 mm

KT 740 mm TRR 1050 mm TRRR 1360 mm TTTR 1600 mm

KL 740 mm LRR 1050 mm RRLR 1360 mm TTRT 1600 mm

TK 740 mm RTT 1170 mm RLRR 1360 mm TRTT 1600 mm

TR 740 mm TRT 1170 mm LRRR 1360 mm RTTT 1600 mm

LK 740 mm TTR 1170 mm TRRT 1480 mm LLLR 1600 mm

LR 740 mm RLL 1170 mm LRRL 1480 mm LLRL 1600 mm

TT 860 mm LRL 1170 mm RTTR 1480 mm LRLL 1600 mm

LL 860 mm LLR 1170 mm TTRR 1480 mm RLLL 1600 mm

LLL 1290 mm RRTT 1480 mm TTTT 1720 mm

TTT 1290 mm RLLR 1480 mm LLLL 1720 mm

LLRR 1480 mm
