500-8067.9 • INSTALLATION AND OPERATING INSTRUCTIONS • 8DJH • Revision 05 43/121
Description
15…17.5 1000 5…6 38.5 80 10…24 442 30 014 43.80 –
1250 5…6 48.2 100 10…24 442 30 022 43,100 –
20…24 20 4 0.75 3.15 10…24 442 30 006 13.3,15 –
50 4 1.5 6.3 10…24 442 30 006 13.6,3 –
75 4 2.2 6.3 10…24 442 30 006 13.6,3 –
100 4 2.9 6.3 10…24 442 30 006 13.6,3 –
10 10…24 442 – 45DB240V10PTD
125 4 3.6 10 10…24 442 30 006 13.10 45DB240V10PTD
160 4 4.7 10 10…24 442 30 006 13.10 –
200 4 5.8 16 10…24 442 30 006 13.16 45DB240V16PTD
250 4 7.3 16 10…24 442 30 006 13.16 45DB240V16PTD
315 4 9.2 16 10…24 442 30 006 13.16 –
20 10…24 442 30 006 13.20 –
25 10…24 442 – 45DB240V25PTD
400 4 11.6 20 10…24 442 30 006 13.20 –
25 10…24 442 30 006 13.25 45DB240V25PTD
500 4 14.5 25 10…24 442 30 006 13.25 45DB240V25PTD
31.5 10…24 442 30 006 13.31,5 45DB240V32PTD
630 4 18.2 31.5 10…24 442 30 006 13.31,5 45DB240V32PTD
40 10…24 442 30 006 13.40 45DB240V40PTD
800 5…6 23.1 31.5 10…24 442 30 006 13.31,5 –
40 10…24 442 30 006 13.40 45DB240V40PTD
1000 5…6 29 50 10…24 442 30 014 13.50 45DB240V50PTS
63 10…24 442 30 014 43.63 –
1250 5…6 36 50 10…24 442 – 45DB240V50PTS
80 10…24 442 30 014 43.80 –
1600 5…6 46.5 100 10…24 442 30 022 43,100 –
2000 5…6 57.8 140 10…24 442 30 022 43,140 –
System operating
voltage
Transformer HV HRC fuse-link Order number for HV HRC fuse-link
U
n
[kV] S
r
[kVA] u
K
[%] I
r
[A] I
r
[A] U
r
[kV] e [mm] Make SIBA Make Mersen
U
n
System operating voltage
S
r
Rated power of transformer
U
K
Relative impedance voltage of transformer
I
r
Rated current of transformer
I
r
Rated current of fuse
U
r
Operating voltage / rated voltage of fuse
e Reference dimension of the fuse
