Siemens Building Technologies Basic Documentation LMV5... CC1P7550en
HVAC Products 14 Technical data 13.08.2004
14 Technical data
14.1 LMV5... and AZL5...
Mains voltage AC 230 V -15 % / +10 %
Transformer AGG5.220
- Primary side
- Secondary side
AC 230 V
AC 12 V
2 x AC 12 V
Mains frequency 50...60 Hz ±6 %
Power consumption (typically) < 30 W
Safety class I with parts according to II and III as per
DIN EN 60 730-1
Storage
DIN EN 60 721-3-1
Climatic conditions class 1K3
Mechanical conditions class 1M2
Temperature range -20...+60 °C
Humidity < 95 % r.h.
Transport
DIN EN 60 721-3-2
Climatic conditions class 2K2
Mechanical conditions class 2M2
Temperature range -20...+70 °C
Humidity < 95 % r.F.
Operation
DIN EN 60 721-3-3
Climatic conditions class 3K5
Mechanical conditions class 3M2
Temperature range (incl. mounting. plate) -20...+60 °C
Humidity < 95 % r.h.
Condensation, formation of ice and ingress of water are not permitted!
Operating voltage AC 24 V -15 % / +10 %
Power consumption (typically) < 5 W
Degree of protection of housing
– Rear
– Front
IP00, IEC 529
IP54, IEC 529 (when built in)
Safety class I with parts according to II and III as per
DIN EN 60 730-1
Storage
DIN EN 60 721-3-1
Climatic conditions class 1K3
Mechanical conditions class 1M2
Temperature range -20...+60 °C
Humidity < 95 % r.h.
Transport
DIN EN 60 721-3-2
Climatic conditions Class 2K3
Mechanical conditions Class 2M2
Temperature range -20...+60 °C
Humidity < 95 % r.F.
Operation
DIN EN 60 721-3-3
Climatic conditions Class 3K3
Mechanical conditions Class 3M2
Temperature range (incl. mounting plate) -20...+60 °C
Humidity < 95 % r.F.
Condensation, formation of ice and ingress of water are not permitted!
Basic unit LMV5...
Environmental
conditions LMV5...
A
ZL...
Environmental
conditions AZL5...
