RUGGEDCOM RX1501
Installation Guide
Chapter 4
Technical Specifications
Cellular Modem Specifications 41
Mode
Connector
Type
Cable
Type (μm)
Tx λ (typ.)
(nm)
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.) (km)
Power
Budget
(dB)
SM LC 9/125 1310 -7 -3 -24 -3 25 17
SFP Gigabit Transceivers
Mode
Connector
Type
Cable
Type (μm)
Tx λ (typ.)
(nm)
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.) (km)
Power
Budget
(dB)
50/125 0.5
MM LC
62.5/125
850 -9 -2.5 -20 0
0.3
11
SM LC 9/125 1310 -9.5 -3 -19 -3 10 9.5
SM LC 9/125 1310 -7 -3 -23 -3 25 16
SM LC 9/125 1550 0 5 -23 -3 70 23
Section 4.6
Cellular Modem Specifications
Conducted Tx (Transmit) Power Tolerances for W11, W12 and W32 (Primary Radio)
Cellular Modems
System/Operating Band Frequency Band (MHz)
Conducted Tx
Power (dBm)
Comment
+32 ± 1 GMSK mode, connectorized (class 4)
GSM-850 and GSM-900
h
850/900
+27 ± 1 8PSK mode, connectorized (class E2)
+29 ± 1 GMSK mode, connectorized (class 1)
DCS-1800 and PCS-1900
h
1800/1900
+26 ± 1 8PSK mode, connectorized (class E2)
Band I 2100
Band II, V, VI and VIII 800, 850, 900 and 1900
+23 ± 1
AMR 12.2 kbps, connectorized (class
3)
h
Circuit-Shared
Typical Radio Frequency (RF) for W21, W22 and W32 (Secondary Radio) Cellular
Modems
Frequency Band (MHz)
System/Operating Band
Transmit (Tx) Receive (Rx)
Conducted Tx Power (dBm)
PCS 1851 to 1910 1930 to 1990
Cellular 824 to 849 869 to 894
23 to 25
Operating Temperature
Module Operating Temperature Compliance
W11, W12, W32 (First Radio) -25 to 60 °C (-13 to 140 °F) Full Radio Frequency (RF) compliance
