8.6 Functional scope with WinCC flexible and WinCC
Basic Panels
Operating Instructions, 04/2012, A5E02421799-03
143
8.6 Functional scope with WinCC flexible and WinCC
The following tables show the objects that can be integrated in a project for a Basic Panel.
Alarms
Object Specification Basic Panels
Number of discrete alarms 200
Number of analog alarms 15
Length of the alarm text 80 characters
Number of tags in an alarm Max. 8
Display Alarm window, alarm view
Acknowledge error alarm individually Yes
Acknowledge multiple error alarms simultaneously
(group acknowledgement)
16 acknowledgment
groups
Edit alarm Yes
Alarms
Alarm indicator Yes
Alarm buffer capacity 256 alarms
Simultaneously queued alarm events Max. 64
View alarm Yes
Alarm buffer
Delete alarm buffer Yes
Tags, values and lists
Object Specification KP300 Basic mono PN
KTP400 Basic mono PN
KP400 Basic color PN
KTP400 Basic color PN
KTP600 Basic mono PN
KTP600 Basic color DP/PN
KTP1000 Basic color DP/PN
TP1500 Basic color PN
Tags Quantity 250 500
Limit value monitoring Input/output Yes
Linear scaling Input/output Yes
Text lists Quantity 150
Screens
Object Specification Basic Panels
Quantity 50
Fields per screen 30
Tags per screen 30
Complex objects per screen (for example, bars) 5
Screens
Template Yes

Siemens SIMATIC HMI KP300 Basic mono PN Specifications

General

Brand	Siemens
Model	SIMATIC HMI KP300 Basic mono PN
Category	Control Panel
Language	English
