Overview
1.7 Design of the KTP600 Basic color DP
Basic Panels
18 Operating Instructions, 04/2012, A5E02421799-03
1.7 Design of the KTP600 Basic color DP


① Power supply connector ⑦ Rating plate
② RS-422/RS-485 interface ⑧ Interface name
③ Cutouts for a mounting clamp ⑨ DIP switch
④ Display/touch screen ⑩ Guide for a labeling strip
⑤ Mounting seal ⑪ Functional earth connection
⑥ Function keys
