Overview
1.9 Design of the KTP1000 Basic color DP
Basic Panels
20 Operating Instructions, 04/2012, A5E02421799-03
1.9 Design of the KTP1000 Basic color DP



① Power supply connector ⑦ Rating plate
② RS-422/RS-485 interface ⑧ DIP switch
③ Cutouts for a mounting clamp ⑨ Interface name
④ Display/touch screen ⑩ Fixing element
⑤ Mounting seal ⑪ Functional earth connection
⑥ Function keys ⑫ Guides for labeling strips
