Basic Panels
Operating Instructions, 04/2012, A5E02421799-03
29
Mounting and connecting
3
3.1 Preparations
3.1.1 Checking the package contents
Check the package content for visible signs of transport damage and for completeness.
NOTICE
Damaged parts
Do not install parts damaged during shipment. In the case of damaged parts, contact your
Siemens representative.
The package content is described in section Product package (Page 22).
Keep the supplied documentation in a safe place. The documentation belongs to the HMI
device and is required for subsequent commissioning.
3.1.2 Checking the operating conditions
Note the following aspects before installing the HMI device:
1. Familiarize yourself with the standards, approvals, EMC parameters and technical
specifications for operation of the HMI device. This information is available in the
following chapters:
– Certificates and approvals (Page 117)
– Electromagnetic compatibility (Page 118)
– Information on insulation tests, p
rotection class and degree of protection (Page 140)
– Power supply (Page 131)
2. Che
ck the mechanical and climatic ambient conditions for operation of the HMI device;
see Conditions of use (Page 138).
3.1.3 Selecting a mounting position
Select one of the approved mounting positions for your HMI device. The approved mounting
positions are described in the following sections.
