Overview
1.4 Design of the KTP400 Basic mono PN
Basic Panels
Operating Instructions, 04/2012, A5E02421799-03
15
1.4 Design of the KTP400 Basic mono PN

① Power supply connector ⑥ Mounting seal
② Functional earth connection ⑦ Guide for a labeling strip
③ PROFINET interface ⑧ Function keys
④ Cutouts for a mounting clamp ⑨ Rating plate
⑤ Display/touch screen ⑩ Interface name
