Installing and connecting the device
3.2 Mounting the device
SIMATIC IPC277G
26 Operating Instructions, 08/2021, A5E50059956-AA
IP65 degree of protection
Risk of electric shock
The specified degree of protection cannot be guaranteed if the device is not correctly
installed. Moisture or water could leak in and cause electric shock or destroy the plant.
The degree of protection IP65 is ensured for the front of the device under the following
conditions:
• The mounting cutout was prepared based on the correct dimensions; see chapter
"Preparing the mounting cutout (Page 23)".
• The device was secured with the supplied mounting clamps or with clamps which can be
optionally ordered.
• The mounting seal is undamaged.
3.2.2 Secure with mounting clips
Positions of the mounting clips
To achieve the degree of protection for the device, the positions for the mounting clips
shown below must be adhered to.
The positions of the mounting clips are marked by stamps on the cutouts. Fit the mounting
clips in all the stamped cutouts.
