Expanding and assigning parameters to the device
6.3 Installing and removing M.2 NVMe/ SATA SSD
SIMATIC IPC277G
Operating Instructions, 08/2021, A5E50059956-AA
55
6.3 Installing and removing M.2 NVMe/ SATA SSD
The device has a slot for M.2 NVMe or SATA SSD on the side of the interface panel.
Requirement
• The device is disconnected from the power supply.
• A M.2 NVMe/SATA SSD that is approved for industrial applications.
• A T10 screwdriver
Procedure - installing the M.2 NVMe/SATA SSD
Remove the two retaining screws.
Pull out the M.2 SSD slot.
Place the thermal pad to the corresponding position of the
M.2 NVMe/SATA SSD chip.
