Technical specifications
8.2 Directives and declarations
SIMATIC IPC277G
74 Operating Instructions, 08/2021, A5E50059956-AA
8.2.2 RoHs directive
This product meets the requirements stated in the RoHS directive (Restriction of Hazardous
Materials): 2011/65/EU
Compliance with the directive has been reviewed according to the following standard: EN
IEC63000
8.2.3 ESD guideline
What does ESD mean?
An electronic module is equipped with highly integrated components. Due to their design,
electronic components are highly sensitive to overvoltage and thus to the discharge of static
electricity. Such electronic components or modules are labeled as electrostatic sensitive
devices.
The following abbreviations are commonly used for electrostatic sensitive devices:
• ESD – Electrostatic sensitive device
• ESD – Electrostatic Sensitive Device as a common international designation
Electrostatic sensitive devices can be labeled with an appropriate symbol.
Damage to ESD from touch
Electrostatic sensitive devices, ESD, can be destroyed by voltages which are far below the
human perception limit. If you touch a component or electrical connections of a module
without discharging any electrostatic energy, these voltages may arise.
The damage to a module by an overvoltage can often not be immediately detected and only
becomes evident after an extended period of operation. The consequences are incalculable
and range from unforeseeable malfunctions to a total failure of the machine or system.
Avoid touching components directly. Make sure that persons, the workstation and the
packaging are properly grounded.
Charge
Every person without a conductive connection to the electrical potential of his/her
surroundings can be electrostatically charged.
The material with which an electrostatically-charged person comes into contact is of
particular significance. The figure shows the maximum electrostatic voltages with which a
person is charged, depending on humidity and material. These values conform to the
specifications of IEC 61000-4-2.
