Technical specifications
8.5 Hardware description
SIMATIC IPC547E
Operating Instructions, 02/2014, A5E32317120-AB
123
8.4.5
Telescopic rails
Ultimate load per pair
≥ 30 kg
Full extraction length
≥ 470 mm
Rail thickness
≤ 9.7 mm
Mounting screws M5 x 6 mm
The mounting screws of the telescopic rails may not protrude by
more than 5 mm into the enclosure.
See also
Dimension drawing for the drilling holes of telescopic rails (Page 113)
8.5
Hardware description
8.5.1
Motherboard
A detailed description of the motherboard and the ports is available in the manual for the
motherboard on the supplied "Documentation and Drivers" DVD.
8.5.2
System resources
All system resources (hardware addresses, memory configuration, allocation of interrupts,
DMA channels) are assigned dynamically by the Windows OS, depending on the hardware
configuration, drivers and connected external devices. You can view the current
configuration of system resources or possible conflicts with the following operating systems:
Microsoft Windows 7 Ultimate
(32-bit and 64-bit)
1. Select in the Windows Start menu "Start" > "Search".
2. Enter "msinfo32" in the search function.
3. Open the application.
Microsoft Windows Server 2008 R2
(64-bit) incl. 5 clients
1. Select in the Windows Start menu "Start" > "Run".
2. Enter "msinfo32" in the Open field and confirm your
input with "OK".
