Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC547E
44 Operating Instructions, 02/2014, A5E32317120-AB
Note
Wait at least ten seconds before you reinsert USB devices.
Note that the EMC immunity of standard USB devices is designed only for office
environments. These USB devices are appropriate for handling
commissioning and service
tasks. Only industrial grade USB devices are permitted for use in industrial environments.
The USB devices are developed and marketed by the respective supplier. The respective
product supplier provides support for the USB devices
. The manufacturer's terms of liability
Note
A monitor should be connected and switched on before device booting to ensure it is
correctly detected and run by the BIOS and the operating system. The screen may otherwise
remain dark.
Note
The connected or added peripherals must not introduce any counter emf into the device.
A counter e.m.f. greater than 0.5 V to ground on the + 3.3 V DC / + 5 V DC / + 12 V DC due
to a connected or integrated component can prevent normal operation or ev
en destroy the
When measuring the counter emf, remember the following:
The computer in question must be turned off and the power supply connector should be
plugged in.
During the measurement, all cables from the plant to the computer should be connected.
All other components in the plant must be active.
Connecting the device to networks
The following options are available for integrating the device into existing or planned system
environments and networks.
Wake on LAN and Remote Boot are supported.
You can use the integrated Ethernet interfaces (10/100/1000 Mbps) for communication and
data exchange with automation devices, such as SIMATIC S7.
You need the "SOFTNET S7" software package for this.
