Siemens SIMATIC NET SCALANCE SC-600 Configuration Manual

Configuring with Web Based Management
4.7 "Security" menu
SCALANCE SC-600 Web Based Management (WBM)
342 Configuration Manual, 10/2021, C79000-G8976-C475-03
• CA Certificate
Select the certificate. Only loaded certificates can be selected.
You load the certificates into the device with "System > Load&Save". The loaded
certificates and key files are shown on the WBM page "Security > Certificates".
• Machine certificate
Select the machine certificate. Only loaded certificates can be selected.
You load the certificates into the device with "System > Load&Save". The loaded
certificates and key files are shown on the WBM page "Security > Certificates".
• User Name
Specify the user name.
• Password
Specify the password.
• Password Confirmation
Confirm the password.
4.7.7.5 Server
On this WBM page, you can create multiple OpenVPN servers per connection.
Description
The page contains the following:
• Name
Enter a name for the OpenVPN server and click "Create".
The table contains the following columns:
• Select
Select the check box in the row to be deleted.
• Name
Shows the name of the OpenVPN server.
