Product overview
2.2 Components, which you require depending on your application
SINAMICS G120C converter
16 Getting Started, 04/2014, FW V4.7, A5E34264105B AA
Use for the intended purpose
The inverter described in this manual is a device for controlling an induction motor. The
inverter is designed for installation in electrical installations or machines.
It has been approved for industrial and commercial use on industrial networks. Additional
measures have to be taken when connected to public grids.
The technical specifications and information about connection conditions are indicated on
the rating plate and in the operating instructions.
2.2
Components, which you require depending on your application
Line reactor
A line reactor protects the converter from the rough characteristics of an industrial grid. A line
reactor supports the overvoltage protection, smoothes harmonics and bridges commutation
notches.
Note
If the relative short
-circuit voltage u
k
of the line transformer is smaller than 1 %, you have to
install a line reactor in order to ensure the optimal lifetime of your converter.
Output reactor
An output reactor allows longer cables between converter and motor.
Braking resistor
The braking resistor enables loads with a large moment of inertia to be braked quickly.
Converter 6SL3210-…
Braking resistor
Line reactor
Output reactor
Frame
Size A
0.55 kW … 1.1 kW …1KE11-81,
…1KE12-31,
…1KE13-21
6SL3201-
0BE14-3AA0
6SL3203-
0CE13-2AA0
6SL3202-
0AE16-1CA0
1.5 kW
…1KE14-31
6SL3203-
0CE21-0AA0
2.2 kW
…1KE15-81
6SL3201-
0BE21-0AA0
3.0 kW … 4.0 kW …1KE17-51,
…1KE18-81
6SL3202-
0AE18-8CA0
Frame
Size B
5.5 kW … 7.5 kW …1KE21-31,
…1KE21-71
6SL3201-
0BE21-8AA0
6SL3203-
0CE21-8AA0
6SL3202-
0AE21-8CA0
Frame
Size C
11.0 kW … 18.5 kW …1KE22-61,
…1KE23-21,
…1KE23-81
6SL3201-
0BE23-8AA0
6SL3203-
0CE23-8AA0
6SL3202-
0AE23-8CA0
