Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
Operating Instructions, 07/2012, A5E03728167
121
Can be changed
Inverter state in which the parameter is changeable. Three states are possible:
● Commissioning: C(1)
● Run: U
● Ready to run: T
This indicates when the parameter can be changed. One, two or all three states may be
specified. If all three states are specified, this means that it is possible to change this
parameter setting in all three inverter states. C(1) shows, that the parameter is only
changeable when P0010 = 1 (quick commissioning).
7.2 Parameter list
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
r0002 Inverter state - - - - - U16 2
Displays actual inverter state.
0 Commissioning mode (P0010 ≠ 0)
1 Inverter ready
2 Inverter fault active
3 Inverter starting (visible only while pre-charging DC link)
4 Inverter running
5 Stopping (ramping down)
6 Inverter inhibited
P0003 User access level 0 - 4 1 U, T - - U16 1
Defines user access level to parameter sets.
0 User defined parameter list - see P0013 for details on use
1 Standard: Allows access into most frequently used parameters
2 Extended: Allows extended access, for example, to inverter I/O functions
3 Expert: For expert use only
4 Service: Only for use by authorized service, password protected
P0004 Parameter filter 0 - 22 0 U, T - - U16 1
Filters parameters according to functionality to enable a more focused approach to commissioning.
0 All parameters
2 Inverter
3 Motor
5 Technology application / units
7 Commands, binary I/O
8 Analog input and analog output
10 Setpoint channel / RFG
12 Inverter features
13 Motor control
19 Motor identification
20 Communication
