Commissioning
5.5 Quick commissioning
SINAMICS V20 Inverter
56 Operating Instructions, 07/2012, A5E03728167
Parameter Access
level
Function Text menu
(if P8553 = 1)
P1003[0] 2 Fixed frequency setpoint 3
(FIX F3)
P2201[0] 2 Fixed PID frequency setpoint 1
(PID F1)
P2202[0] 2 Fixed PID frequency setpoint 2
(PID F2)
P2203[0] 2 Fixed PID frequency setpoint 3
(PID F3)
5.5.2 Quick commissioning through the parameter menu
As an alternative to quick commissioning through the setup menu, commissioning using the
parameter menu provides the other solution for quick commissioning. This would be helpful
for those who are used to commissioning the inverter in this way.
Setting parameters
NOTICE
In the table below, "●" indicates that the value of this parameter must be entered according
to the rating plate of the motor.
Parameter Function Setting
P0003 User access level = 3 (Expert access level)
P0010 Commissioning parameter = 1 (quick commissioning)
P0100 50 / 60 Hz selection Set a value, if necessary:
=0: Europe [kW], 50 Hz (factory default)
=1: North America [hp], 60 Hz
=2: North America [kW], 60 Hz
P0304[0] ● Rated motor voltage [V] Range: 10 ... 2000
Note:
The input of rating plate data must correspond with the wiring of
the motor (star / delta)
