Commissioning
5.4 Starting the motor for test run
SINAMICS V20 Inverter
38 Operating Instructions, 07/2012, A5E03728167
5.4 Starting the motor for test run
This section explains how to start the motor for a test run to check that the motor speed and
rotation direction are correct.
NOTICE
To run the motor, the inverter must be in the display menu (default display) and power-on
default state with P0700 (selection of command source) = 1.
If you are now in the setup menu (the inverter displays "P0304"), press
M
for longer than
two seconds to exit the setup menu and enter the display menu.
You can start the motor in HAND or JOG mode.
Starting the motor in HAND mode
1. Press to start the motor.
2. Press
to stop the motor.
Starting the motor in JOG mode
1. Press
M
+
OK
to switch from HAND to JOG mode (the . icon flashes).
2. Press
to start the motor. Release to stop the motor.
5.5 Quick commissioning
5.5.1 Quick commissioning through the setup menu
5.5.1.1 Structure of the setup menu
Functionality of the setup menu
The setup menu guides you through the main steps required for quick commissioning of the
inverter system. It consists of the following four sub-menus:
Sub-menu Functionality
1 Motor data Sets nominal motor parameters for quick commissioning
2 Connection macro selection Sets macros required for standard wiring arrangements
3 Application macro selection Sets macros required for certain common applications
4 Common parameter selection Sets parameters necessary for inverter performance
optimization
