Siemens SIPART DR19 User Manual

SIPART DR19
80 C73000-B7474-C140-06
Configuring Quick Reference
3.7 AdAP - End-Adaptation
During adaptation the signal lamp ADAPT (16) flashes. The duration of the adap-
tation depends on the delay in the process.
You can switch from automatic to manual mode or from manual to automatic mode
during adaptation - press button (9) once.
The adaptation process can be ended in the following ways:
• Adaptation ended error-free (automatic);
• Adaptation is aborted manually;
• Adaptation is aborted automatically
If adaptation is ended in automatic mode:
If adaptation is ended in manual mode:
By pressing the exit button (13)
By error monitoring:
Signal lamp AdAPT (16): off
Operation and monitoring front: process control level
Controller operating mode: automatic mode,
the controller operates according to
the new control parameters.
Signal lamp AdAPT (16): off
Operation and monitoring front: process control level
Controller operating mode: manual mode,
the output manipulated value y
causes as small a control difference
as possible
After switching to automatic mode, the controller operates according to the new
control parameters.
Signal lamp AdAPT (16): off
Operation and monitoring front: process control level
Controller operating mode: manual mode (YS is output)
The original control parameters are retained.
Signal lamp AdAPT (16): off
Operation and monitoring front: selection level l
Controller operating mode: manual mode (YS is output)
Adaptation
process
End of
adaptation
Adaptation
is ended
without
error
Adaptation
is aborted
manually
