Siemens SIPART DR19 User Manual

SIPART DR19
C73000-B7474-C140-06
91
Quick Reference Explanation of abbreviations
6 Explanation of abbreviations
Subject Explanation see
± ∆w DO: Setpoint adjustment, increase/decrease (only with
S1=4, M/A control station)
StrS S68/S69
± ∆y DO: Manipulated variable y for S controller and two-step
controller (S1=2/3)
StrS S58
± yBL DI: Blocking of manipulated variable, directional StrS S29/S30
A1 to
A4
Parameter: Set alarm value for A1 to A4
DO: Message "Alarms A1 to A4 triggered"
oFPA page 58
StrS S63 to S66
APSt Configuring mode "All preset", reset to factory setting APSt page 81
DO General abbreviation for "Digital signal output" --
DI General abbreviation for "digital signal input" --
bLb DI: Block operation StrS S31
bLPS DI: Block configuring modes StrS S33
bLS DI: As bLPS, but without onPA StrS S32
CB DI: Switchover between internal/external setpoint StrS S23/S42
dA Parameter: w/x digital display, setting of start of scale oFPA page 58
dE Parameter: w/x digital display, setting of full-scale value oFPA page 58
dP Parameter: w/x digital display, setting of decimal point oFPA page 58
H Operating mode: Manual mode of controller
DO: Message "Controller in manual mode"
--
StrS S61
HA Parameter: Hysteresis of alarms A1 to A4 oFPA page 58
He DI: Switchover to manual mode StrS S24/S52
MUF DO: Signal "Transmitter monitoring function triggered" StrS S67
N Operating: Tracking mode of manipulated mode variable y
DI: Switchover to tracking mode
--
StrS S25
Nw DO: Message "Setpoint ramp active" StrS S62
oFPA Configuring mode "Set offline parameters" Configuring
page 55
onPA Configuring mode "Set online parameters" Configuring
P DI: Swtichover from Pi controller to P controller StrS S27
PU DI: Program controller, program switchover P1 - P2 StrS S34
RB
(RB
)
DO: Message "Computer mode of controller not ready" StrS S59
