SIPART DR19
C73000-B7474-C140-06
81
Quick Reference Configuring
The following error messages may appear in the PV-X (1) and SP-W (2) displays:
To exit the adaptation function:
Press button (13) once (process control level).
Manual mode with YS remains operational.
3.8 APSt - All Preset
Controller is reset to factory setting.
Error message Significance
SP.Pv (1)
SMAL (2)
Setpoint- actual value difference < 20%
over (1)
Shot (2)
Overshoot during adaptation > 10 %
n (1)
ModE (2)
Tracking mode via control signals
Si (1)
ModE (2)
Safety mode via control signals
+
NOTE
All settings are restored to their original factory settings. The APSt function can-
not be undone!
Step Procedure
1 Press button (6) about 5 sec until "PS" flashes. Release button -
"onPA" (selection level) displayed. Blocked if digital signal bLPS=1.
2 Press button (8) several times until "APSt" is displayed (selection
level). Blocked if digital signal bLS=1.
3 Press button (9) for about 3 sec until "no" appears (configuring level).
Controller is blocked, last value of y is retained.
4 Press button (8) once, "YES" appears (configuring level).
5 Press button (9) for about 5 sec until "StrS" appears (selection level).
6 Press button (13) once (process control level). It the parameters and
configuring switches of the controller are now in the factory setting. The
controller is in manual mode.
Function
Execution o
f
APSt func-
tion
