Siemens SIPART DR19 User Manual

SIPART DR19
C73000-B7474-C140-06
83
Quick Reference Block Diagram
4.1 Input Circuits
Controllers Type S1=0, 1, 2
S1 = 0 Fixed setpoint controller with one or two setpoint values
S1 = 1 Fixed setpoint controller with five setpoint values
S1 = 2 Slave/SPC-controller with internal/external switchover
wi1
INT ^ CB
0000
w
wi2
0000
x
x = x1 + c1 (x2 - c2 x3 + c3)
x1
x2
x3
PID
yH
y
ya
w
x
xd
+
-
wi1
INT
0000
w
0000
x
x = x1 + c1 (x2 - c2 x3 + c3)
x1
x2
x3
PID
yH
y
ya
w
x
xd
+
-
INT
SH4
CB ^ PU
SH3
CB ^ PU
SH2
CB ^ PU
SH1
CB ^ PU
wi1
INT ^ CB
0000
w
wES
0000
x
x = x1 + c1 x2 + c3
x1
x2
PID
yH
y
ya
w
x
xd
+
-
x3/wEA
2, 3
S93
0, 1
w
E = c4 we + c5
