SITOP PSU100S
Operating Instructions, 02.2013, C98130-A7589-A1-3-7629
39
Technical data
6
Note
Technical data is applicable for a rated input voltage, rated load and +25° C ambient
temperature (if nothing else is specified).
6.1 Input
6EP1332-2BA20 6EP1333-2BA20 6EP1334-2BA20 6EP1336-2BA10
Input 1-phase, AC
Rated voltage
Ue rated
120 / 230 V
Voltage range 85-132 / 170-264 V 85-132 / 176-264 V
automatic range
switchover
Yes
Connect/shutdown
threshold, typical
80 V / 61 V 77 V / 63 V 70 V / 66 V 80 V/78 V or
160 V/155 V
Power failure buffering
at Ia rated, min
20 ms 20 ms 20 ms 20 ms
Power-failure buffering at 93 / 187 V at 120 / 230 V
Rated line frequency 50/60 Hz
Line frequency range 47...63 Hz
Input current / at rated
value of input voltage
120 V
1.25 A 2.34 A 4.49 A 7.5 A
Input current / at rated
value of input voltage
230 V
0.74 A 1.36 A 1.91 A 3.5 A
Switch-on current
limitation (+25 °C),
max.
33 A 40 A 60 A 11 A
I²t, at 120 V AC, max 0.1 A
2
s 0.3 A
2
s 1.6 A
2
s 2.5 A
2
s
I²t, at 230 V AC, max. 0.4 A
2
s 1.0 A
2
s 5.6 A
2
s 10 A
2
s
Integrated input fuse Fuse T 3.15 A Fuse T 3.15 A Fuse T 6 A Fuse T 10 A
