Technical data
6.7 Mechanical system
SITOP PSU100S
52 Operating Instructions, 02.2013, C98130-A7589-A1-3-7629
6.7 Mechanical system
6EP1332-2BA20 6EP1333-2BA20
6EP1322-2BA00
6EP1334-2BA20
6EP1323-2BA00
6EP1336-2BA10
Connection system Screw-type terminal
Connections / line
supply
L, N, PE: 1 screw terminal each for 0.5 ... 2.5 mm² solid/finely stranded L1, N, PE: 1 screw
terminal each for 0.2 ...
4 mm² solid/finely
stranded
Connections / output +, -: 2 screw terminals each for 0.5 ... 2.5 mm² +, -: 2 screw terminals
each for 0.2 ... 4 mm²
Connections / auxiliary
contacts
Signals: 2 screw terminals for 0.5 mm ... 2.5 mm² 13, 14 (signal): 1
screw terminal each
for 0.14 ... 1.5 mm²
Width of the housing 32.5 mm 50 mm 70 mm 115 mm
Height of the housing 125 mm 125 mm 125 mm 145 mm
Depth of the housing 120 mm 120 mm 120 mm 150 mm
Installation width 32.5 mm 50 mm 70 mm 120 mm
Mounting height 225 mm 225 mm 225 mm 245 mm
Weight, approx. 0.32 kg 0.5 kg 0.8 kg 2.4 kg
Product feature of the
housing / housing that
can be lined up next to
one another
Yes
Type of mounting /
panel mounting
No
Type of mounting / rail
mounting
Yes
Type of mounting / S7-
300 rail mounting
No
Mounting Can be snapped onto standard EN 60715 35x7,5/15 mounting rails
