Siemens SITOP PSU100S User Manual

Technical data
6.5 Protection and monitoring
SITOP PSU100S
Operating Instructions, 02.2013, C98130-A7589-A1-3-7629
51
6.5 Protection and monitoring
6EP1332-2BA20 6EP1333-2BA20 6EP1334-2BA20 6EP1336-2BA10
Output overvoltage
protection
Yes, according to EN 60950
Current limitation
Typ.
 Remark
3.75 A
Overload capability
with
150 % Ia rated up to
5 s/min
7.5 A
Overload capability
with
150 % Ia rated up to
5 s/min
15 A
Overload capability
with
150 % Ia rated up to
5 s/min
21.5 A (>45 °C)
25.5 A (<45 °C)
Overload capability
with
150 % Ia rated up to
5 s/min
Short-circuit protection Yes, current is statically limited Electronic trip,
automatic restart
(hiccup)
Continuous short-
circuit current rms
value, approx.
3.4 A 7.3 A 14.6 A 7 A
Overload / short-circuit
display
-
6EP1322-2BA00 6EP1323-2BA00
Output overvoltage protection Yes, according to EN 60950
Current limitation, typ.
 Remark
10.5 A
Overload capability with
150 % Ia rated up to 5 s/min
21 A
Overload capability with
150 % Ia rated up to 5 s/min
Short-circuit protection Yes, current is statically limited
Continuous short-circuit current
rms value, approx.
8.8 A 16.4 A
Overload / short-circuit display -
6.6 MTBF
6EP1332-2BA20
6EP1333-2BA20
6EP1334-2BA20
6EP1322-2BA00
6EP1323-2BA00
6EP1336-2BA10
Mean Time Between Failures SN29500:
> 1600000 h
at 40 °C, rated load, 24 h operation
SN29500:
>500000 h (typ. 700000 h)
at 40° C, rated load, 24 h operation
