Safety, approvals, EMC
7.4 EMC
SITOP PSU100S
58 Operating Instructions, 02.2013, C98130-A7589-A1-3-7629
7.4 EMC
6EP1332-2BA20
6EP1333-2BA20
6EP1334-2BA20
6EP1322-2BA00
6EP1323-2BA00
6EP1336-2BA10
Electrostatic
discharge
EN 61000-4-2 8 kV contact, 8 kV air 8 kV contact, 8 kV air
Electromagnetic
fields
EN 61000-4-3 80…1000 MHz 10 V/m
1400…2000 MHz 10 V/m
2000…2700 MHz 10 V/m
895…905 MHz and 1.89 GHz 10 V/m
80…1000 MHz 15 V/m
1000…2700 MHz 10 V/m
High-speed transient
disturbance variables
(burst)
EN 61000-4-4 2 kV at line connections
1 kV at DC output
4 kV at line connections
2 kV at DC output
Surge voltages EN 61000-4-5 2 kV symmetrical at the line connections
4 kV symmetrical at the line connections
500 V symmetrical/asymmetrical on DC output cables
High-frequency fields EN 61000-4-6 10 V; 0.15…80 MHz 10 V; 0.15…80 MHz
Magnetic fields EN 61000-4-8 Not applicable 30 A/m; 50 Hz
Voltage dips EN 61000-4-11 100% for 20 ms,
60% for 200 ms,
30% for 500 ms
100% for 20 ms,
60% for 200 ms,
30% for 500 ms
Voltage interruptions EN 61000-4-11 100% for 5000 ms 100% for 5000 ms
Emitted interference EN 55022 Class B Class B
Line harmonics
limitation
EN 61000-3-2 Class A Class A
EN 61000-6-2 Immunity for industrial environments Generic standards
EN 61000-6-3 Emission for residential areas
