Instruments and Indicator Lights
Instrument cluster
Introduction
This chapter contains information on the following subjects:
Overview 30
Revolution counter 31
Display 31
Speedometer 31
Coolant temperature gauge 32
Fuel gauge 32
Counter for distance driven 33
33
Display of the second speed 33
Auto Check Control 33
The instrument cluster gives the driver basic information such as the current
speed, engine speed, the state of some vehicle systems and the like.
Fault display
If there is a fault in the instrument cluster, the Error message will appear in
the display.
Seek help from a specialist garage.
WARNING
Concentrate fully at all times on your driving! As the driver you are fully re-
sponsible for road safety.
Note
When the ignition is on, the instrument cluster is illuminated
1)
. The brightness
level is automatically adjusted depending on the ambient lighting.
Overview
Fig. 20 Instrument cluster - Version 1
Fig. 21 Instrument cluster - Version 2
Read and observe on page 30 first.
Engine revolutions counter » page 31
›
with warning lights » page 34
Display » page 31
1
2
1)
Applies to cars with the instrument cluster - Version 1.
30
