Raptor
94
SPECIFICATIONS
Raptor-MS
Raptor-MS master unit
(values @240 Vac, 50 Hz, 1 sec. turn 960 mm2, measured 25 cm on each side)
HIGH CURRENT OUTPUT
Output Current Output Voltage
No Load V (0%Imax) 0-1,20 Vac - Continuous
3,8 KAac (25%Imax) 0-0,81 Vac - Continuous
7,5 KAac (50%Imax) 0-0,42 Vac - 3 min
9,5 KAac (63%Imax) 0-0,22 Vac - 3 s
No Load Resolution 25 uVac
Output Frequency 20-400 Hz
(Power reduction applied at 50 < f > 60 Hz)
LOW CURRENT OUTPUT
(Not simultaneous with high current output)
Output Current 0-35 Aac (0 – 9 Aac continuous)
Voltage Output 0-200 Vac
Output Frequency 20-400 Hz
(Power reduction applied at 50 < f > 60 Hz)
Isolated output yes
Protection fuse
MEASUREMENTS
Secondary Current
(for high current output)
Ranges 0-1 / 0-15 KAac
Resolution 1 Aac, 10 Aac
Accuracy ±0,2% of the value ±0,2% of the range
Phase angle
±0,25°
Ammeter/Low Level Voltmeter
Amm. Ranges 0-0,2 /0-2/0-20 Aac
•
Amm.Resolution
0,1 mAac, 1 mAac, 10 mAac
Amm. Impedance <10 mΩ
Volt. Ranges 0-30 mVac,0- 0,3 Vac, 0- 3 Vac
Volt. Resolution 0,015 mVac, 0,15 mVac, 1,5 mVac
Volt. Impedance >3000 KΩ
Frequency range 20-400 Hz
Accuracy ±0,1% of the value ±0,1% of the range
Phase angle
±0,25°
Isolated input yes
Voltmeter
Ranges 0-0,2/0-2/0-20/0-300 Vac
Resolution 0,1 mVac, 1 mVac, 10 mVac, 0,15 Vac
Impedance >120 KΩ
Frequency range 20-400 Hz
