— Quick Reference —
Identifying parts and controls
1 Lens cap (p. 25)
2 LCD/Touch panel screen (p. 23, 28, 29)
3 RESET button (p. 193)
If you press RESET, all the settings
including the date and time return to
the default.
4 BACK LIGHT button (p. 33)
5 Speaker
Camcorder
6 DSPL/BATT INFO button (p. 20, 40)
7 CHG (charge) lamp (p. 17)
8 Eyecup (p. 206)
9 Viewfinder (p. 31)
0 START/STOP button (p. 9, 25, 125)
qa Battery pack mounting surface (p. 16)
qs Hooks for shoulder strap
1
8
2
9
3
q;
4
qa
5
6
qs
Attaching the supplied lens cap
1 Align the lens cap to
the groove.
2 Push the lens cap
against the lens until it
snaps.
When recording, open
the lens cap as shown.
Note
Position the lens cap so as not to
cover the microphone and the
remote sensor.
To Next Page
