HCD-FC8/FC9
3-18. TIMING BELT (FRONT/REAR)
1 screw
(PTPWH2.6 × 8)
3 screw
(PTPWH2.6 × 8)
7 screw
(PTPWH2.6 × 8)
9 screw
(PTPWH2.6 × 8)
qa screw
(PTPWH2.6 × 8)
qs cam (gear)
5 screw
(PTPWH2.6 × 8)
2 pulley
(mode deceleration)
4 gear
(mode 5)
8 gear (mode 3)
0 gear
(mode 2)
6 gear (mode 4)
3 slider (mode cam) assy
5 two gears
(center)
7 two gears (center)
8 timing belt (rear)
timing belt
(rear)
When install three timing belts,
its pass under each claws.
9 timing belt (rear)
4 gear
(timing)
2 gear (mode cam)
6 timing belt
(front)
1 screw
(PTPWH2.6
× 8)
timing belt
(rear)
timing belt (front)
two claws
two claws
two claw
s
two claws
