HCD-FC8/FC9
7-27. PRINTED WIRING BOARD – DDCOM SECTION – • See page 35 for Circuit Boards Location.
• : Uses unleaded solder.
IC800
13
PREV NEXT
TO
KEY
BOARD
CN818
(Page 66)
TO
DVD
BOARD
CN005
(Page 45)
TO
FL
BOARD
CN816
(Page 66)
M H N
VOLUME
BASS LEVEL
-
+
12
A
B
C
D
E
F
3456
• Semiconductor
Location
Ref. No. Location
D806 D-4
D807 D-4
D808 D-4
D809 D-4
D810 D-3
D812 F-2
IC800 B-2
Q803 D-3
Q804 D-4
