71
HCD-IS10
SECTION 8
ELECTRICAL PARTS LIST
DMB-IVHD
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
9 A-1313-854-A DMB-IVHD BOARD, COMPLETE (for SERVICE)
(US, CND)
9 A-1313-856-A DMB-IVHD BOARD, COMPLETE (for SERVICE)
(AEP, UK)
9 A-1313-858-A DMB-IVHD BOARD, COMPLETE (for SERVICE)
(RU)
9 A-1313-859-A DMB-IVHD BOARD, COMPLETE (for SERVICE)
(SP, TW, TH)
9 A-1313-860-A DMB-IVHD BOARD, COMPLETE (for SERVICE)
(CH)
9 A-1313-861-A DMB-IVHD BOARD, COMPLETE (for SERVICE)
(EA)
9 A-1313-862-A DMB-IVHD BOARD, COMPLETE (for SERVICE)
(AUS)
9 A-1313-863-A DMB-IVHD BOARD, COMPLETE (for SERVICE)
(E32)
9 A-1313-865-A DMB-IVHD BOARD, COMPLETE (for SERVICE)
(AR)
*************************
< CAPACITOR >
C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C102 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C105 1-128-994-21 ELECT CHIP 47uF 20% 10V
C106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C112 1-128-994-21 ELECT CHIP 47uF 20% 10V
C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C114 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C115 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-124-779-00 ELECT CHIP 10uF 20% 16V
C118 1-124-779-00 ELECT CHIP 10uF 20% 16V
C119 1-124-779-00 ELECT CHIP 10uF 20% 16V
C120 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C121 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C122 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C123 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C124 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C125 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C127 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C128 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C130 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C131 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C132 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C133 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C135 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C136 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C137 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C138 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C139 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C140 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C144 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C145 1-124-779-00 ELECT CHIP 10uF 20% 16V
C146 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C147 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C148 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C149 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C150 1-124-779-00 ELECT CHIP 10uF 20% 16V
C151 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C152 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C153 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C154 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C155 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C156 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C157 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C158 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C160 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C161 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C162 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C163 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C164 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C169 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C170 1-124-779-00 ELECT CHIP 10uF 20% 16V
C171 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C172 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C173 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• Abbreviation
AR : Argentina model
AUS: Australian model
CH : Chinese model
CND : Canadian model
E32 : Latin America models except
Argentina
EA : Saudi Arabia model
RU : Russian model
SP : Singapore model
TH : Thai model
TW : Taiwan model
The components identified by mark 9 contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifiés par la marque 9
contiennent des informations confidentielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé et /
ou réparé.
When indicating parts by reference number,
please include the board.
Ver. 1.1
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiquens pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
