MHC-V11
6
Note: Follow the disassembly procedure in the numerical order given.
2-2. LEFT SIDE COVER, RIGHT SIDE COVER
1 two screws
4 right side cover
3 claw
2 two screws
4 left side cover
3 claw
2 two screws
1 screw
1 screw
