Sony MHC-V4D Service Manual

86
MHC-V3/V4D
SECTION 8
ELECTRICAL PARTS LIST
A-2057-278-A ARAGON BOARD, COMPLETE (for SERVICE)
(V4D: E2, E51, MX, AR)
A-2057-279-A ARAGON BOARD, COMPLETE (for SERVICE)
(V4D: MY, TH)
A-2057-280-A ARAGON BOARD, COMPLETE (for SERVICE)
(V4D: SAF, EA, E4)
A-2057-360-A ARAGON BOARD, COMPLETE (for SERVICE)
(V3: E2, E51)
A-2057-362-A ARAGON BOARD, COMPLETE (for SERVICE)
(V3: AUS)
*******************************
< CAPACITOR >
* C003 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C004 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C005 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C006 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C010 1-118-358-11 CERAMIC CHIP 100PF 1% 50V
C011 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C013 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C014 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C017 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C018 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C019 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C021 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C030 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C032 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C034 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C035 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C036 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C039 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C040 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C043 1-216-864-11 SHORT CHIP 0
C044 1-216-864-11 SHORT CHIP 0
C045 1-216-864-11 SHORT CHIP 0
* C049 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C050 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C051 1-114-814-11 CERAMIC CHIP 0.33uF 10% 25V
* C052 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C053 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C057 1-117-681-11 ELECT CHIP 100uF 20% 16V
C062 1-114-814-11 CERAMIC CHIP 0.33uF 10% 25V
C064 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
* C065 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C066 1-165-492-21 ELECT CHIP 100uF 20% 10V
C067 1-165-492-21 ELECT CHIP 100uF 20% 10V
* C068 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C071 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C072 1-135-366-11 ELECT CHIP 100uF 20% 16V
C073 1-165-492-21 ELECT CHIP 100uF 20% 10V
C074 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C075 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C078 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C079 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C080 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C081 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C083 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C084 1-117-681-11 ELECT CHIP 100uF 20% 16V
* C085 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C086 1-216-864-11 SHORT CHIP 0
C087 1-124-779-00 ELECT CHIP 10uF 20% 16V
* C088 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C090 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
* C091 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
* C102 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C103 1-124-779-00 ELECT CHIP 10uF 20% 16V
C104 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
* C106 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C107 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C109 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
* C110 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C111 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C112 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C113 1-164-938-11 CERAMIC CHIP 0.0015uF 10% 50V
* C114 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C115 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C116 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C117 1-218-965-11 METAL CHIP 10K 5% 1/16W
* C118 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C120 1-218-965-11 METAL CHIP 10K 5% 1/16W
* C121 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C122 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C123 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C126 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
• Abbreviation
AR : Argentina model
AUS : Australian model
E2 : 120 V AC area in E model
E4 : African model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
MY : Malaysia model
SAF : South African model
TH : Thai model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
ARAGON
The components identifi ed by mark 9
contain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Ver. 1.5

Sony MHC-V4D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Bass reflex	-
Speaker type	3-way
RMS rated power	720 W
Woofer diameter	200 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
Equalizer modes	Custom, Pop, Flat, Rap, Rock
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Composite video out	1
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	English
Playback modes	Program, Shuffle, Repeat, Normal
Audio formats supported	WMA, MP3
Display type	LCD

Weight and Dimensions

Depth	295 mm
Width	280 mm
Height	780 mm
