Sony MHC-V50 Service Manual

MHC-V50/V50D
MHC-V50/V50D
5252
6-25. PRINTED WIRING BOARD - BACK PARTY LIGHT R Board -
• See page 32 for Circuit Boards Location. • : Uses unleaded solder.
6-23. PRINTED WIRING BOARD - BACK PARTY LIGHT L Board -
• See page 32 for Circuit Boards Location. • : Uses unleaded solder.
6-26. SCHEMATIC DIAGRAM - BACK PARTY LIGHT R Board - 6-24. SCHEMATIC DIAGRAM - BACK PARTY LIGHT L Board -
1
A
B
C
D
E
234
D3700D3701 D3702
1
2
4
5
CN3700
CL1652
CL1657
CL1656
CL1653
CL1651
CL1654
CL1655
R1651
R1652
R1653
1-981-713-
11
(11)
1-981-713-
11
(11)
BACK PARTY LIGHT L BOARD
BACK PARTY LIGHT L BOARD
(COMPONENT SIDE)
(CONDUCTOR SIDE)
>015P
PARTY LIGHT DRIVER BOARD
CN1401
(Page 50)
1
A
B
C
D
E
234
D3703 D3704 D3705
CL3701
CL3702
CL3703
CL3704
CL3707
CL3705
CL3706
1
24
5
CN3701
R3701
R3702
R3703
1-981-714-
11
(11)
1-981-714-
11
(11)
BACK PARTY LIGHT R BOARD
BACK PARTY LIGHT R BOARD
(COMPONENT SIDE)
(CONDUCTOR SIDE)
>014P
PARTY LIGHT DRIVER BOARD
CN1402
(Page 50)
1
A
B
2 3 4 5 67
CL1656
CL1654
CL1653
CL1652
CL1655
CL1657
CL1651
0
R1652
10
R1653
0
R1651
5P
CN3700
1
M +5.2V
2
M +5.2V
3
BLUE HILED
4
RED HILED
4
GREEN HILED
GD DASPA1.14-RMRO-W5-1
D3700
GR DASPA1.23-FSFU-26-1
D3702
GT DASPA1.13-GRGT-26-1
D3701
BACK PARTY LIGHT L BOARD
>005S
PARTY LIGHT
DRIVER BOARD
CN1401
(Page 51)
1
A
B
2 3 4 5 67
CL3707
CL3704
CL3703
CL3702
CL3705
CL3706
CL3701
0
R3702
10
R3703
0
R3701
5P
CN3701
1
M +5.2V
2
M +5.2V
3
BLUE HILED
4
RED HILED
4
GREEN HILED
GD DASPA1.14-RMRO-W5-1
D3703
GR DASPA1.23-FSFU-26-1
D3704
GT DASPA1.13-GRGT-26-1
D3705
BACK PARTY LIGHT R BOARD
>011S
PARTY LIGHT
DRIVER BOARD
CN1402
(Page 51)

Sony MHC-V50 Specifications

General

Type	Home audio tower system
Cassette deck	No
Product color	Black
Disc loading type	Tray
Optical disc player	Yes
Number of optical discs	1 discs
Coloration	Monochromatic
Bluetooth profiles	A2DP, AVRCP, SPP
Illumination location	Front
Analog signal format system	NTSC, PAL
Speaker type	3-way
RMS rated power	660 W
Woofer diameter	200 mm
Tweeter diameter	40 mm
Number of speakers	1
Mid-range driver diameter	80 mm
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	20
Recording on	USB
Playback modes	Normal, Repeat, Shuffle
Playback disc formats	CD audio, DVD-Audio, VCD
Audio formats supported	AAC, MP3, WAV, WMA
Video formats supported	MPEG1, MPEG4, XVID
Volume control	Digital
Power source	AC
Power consumption (standby)	0.5 W
Power consumption (typical)	120 W

Weight and Dimensions

Depth	300 mm
Width	293 mm
Height	798 mm
Weight	14000 g
