Sony SA-S350 User Manual

HT-S350/SD35
9
Sony CONFIDENTIAL
For Authorized Servicer
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-2. TOP PANEL BLOCK
(Page 10)
2-8. GRILLE ASSY
(Page 15)
2-3. WIRE WITH LUG TERMINAL,
FFC (6 CORE) (L=138 mm)
(Page 11)
2-5. BT MODULE
(Page 13)
2-7. AC CORD
(Page 14)
2-6. IR RP BOARD
(Page 13)
2-9. SPEAKER UNIT
(Page 16)
2-11. CHASSIS BLOCK-1
(Page 18)
2-14. MAIN BOARD-1
(Page 21)
2-10. LED BOARD
(Page 17)
2-16. POWER BOARD
(Page 23)
2-4. TOUCH KEY BOARD
(Page 12)
2-15. MAIN BOARD-2,
FFC (6 CORE) (L=161 mm)
(Page 22)
2-13. CHASSIS BLOCK-3
(Page 20)
2-12. CHASSIS BLOCK-2
(Page 19)
SYSSET
