Stiga Primo 2008 User Manual

Edition Manual Chapter Page
2008-03-18 Workshop Manual, Stiga Primo 2 Chassis and Body 1
2 Chassis and body
Contents in this chapter
General
To facilitate the driving, handling of work equipment and to make it comfortable for the
driver, the machines are equipped with a various number of aid equipments.
This chapter gives a brief description of the equipments and describes their repair and
replacements.
This chapter also contains information about how to repair the plastic chassis including
material and threads.
2.3 Lubrication chassis .................... 4
2.3.1 Drive chain............................... 4
2.3.2 Steering cable.......................... 4
2.3.3 Tensioning arms, movable joints5
2.3.4 Throttle cable........................... 5
2.3.5 Bearings................................... 5
2.1 Repair of the chassis...................2
2.1.1 Repair of cracks........................2
2.1.2 Repair of threads......................2
2.2 Wheel ............................................3
2.2.1 Adjusting the drive chain (U) ....3
