Edition Manual Chapter Page
2008-03-18 Workshop Manual, Stiga Primo 4 Belts 1
4 Belts
Contents in this chapter
General
All mechanical power, delivered by the motor, is conducted to the different power
consuments by a belt system. The maximum tension of each belt is regulated by a spring
loaded belt tensioner.
This chapter gives a brief description of the belt system and describes replacements of
belts and adjustments of their tensions.
This chapter is valid for the actual machines where the actual system occur.
4.1 Description................................. 2
4.2 Belt theory..................................3
4.2.1 Why it is so important to use
original belts from the
retail dealer? ...........................3
4.3 Replacement of belts ................5
4.3.1 Disassembly of belt C ............5
4.3.2 Inspection and measures....... 6
4.3.3 Assembly of belt C ................. 7
4.3.4 Adjustmen of PTO brake........ 7
