8
BT 130
3.2
Auger Brake
Condition
Cause
Remedy
Drilling tool (auger)
stops under full
load
Brake band blocked
Check freedom of movement and
operation of brake ban
d
Auger does not stop immediately
when brake is activated
Auger brake spring
stretched / broken
Install new auger brake spring
Brake band
stretched / worn / broken
Install new brak
e band
Clutch drum worn
Install new clutch drum
74
76
Table of Contents
Default Chapter
68
Table of Contents
68
1 Introduction and Safety Precautions
69
Introduction
69
Safety Precautions
70
2 Specifications
71
Engine
71
Fuel System
71
Ignition System
71
Gearbox
71
Tightening Torques
72
3 Troubleshooting
74
Clutch
74
Auger Brake
75
Gearbox
76
Rewind Starter
77
Ignition System
78
Carburetor
79
Engine
83
4 Clutch
85
Clutch Drum
85
Clutch
88
Fan Housing
90
5 Auger Brake
91
Checking
91
The Auger Brake
91
Brake Band
91
Brake Lever
92
Pins
94
6 Gearbox
95
7 Engine
98
Removing and
98
Shroud
99
Air Guide Shroud
99
8 Short Circuit Wire
100
Testing
100
Short Circuit Wire on Engine - Removing and Installing
100
Removing and Installing
102
Ground Wire
103
Ignition System Troubleshooting
104
9 AV Elements
107
Rubber Buffers on Handlebar
107
10 Control Levers
109
Control Handle - Removing and Installing
109
Throttle Trigger / Lockout Lever
110
10.1.2 Slide Control
112
Adjusting the Throttle Cable
113
11 Handlebar / Handle Frame
115
Handle Tubes
115
Handle Frame
116
12 Special Servicing Tools
117
13 Servicing Aids
118
