Stihl FS 80 Service Manual

56 FC 75, FC 85, FH 75, FS 75, FS 80, FS 85, HL 75, KM 85, KW 85
Pickup body
: Use hook (1) 5910 893 8800 to
pull the pickup body out of the
fuel tank. Take care not to over-
stretch the fuel hose in the
process.
VA
936RA179
1
: Pull the pickup body off the fuel
hose.
– Fit a new pickup body.
Install in the reverse sequence.
VA
936RA180
Fuel tank
: Remove the fuel tank.
– Remove the fuel hoses if
necessary.
Install in the reverse sequence.
VA
936RA182
: The lugs (1) must engage the
plugs (2).
VA
936RA183
21
Fuel hoses
– Unscrew the filler cap and
remove it together with the cap
retainer.
: Use hook (1) 5910 893 8800 to
pull out the pickup body.
VA
936RA184
1
: Pull the pickup body off the fuel
hose.
VA
936RA185
