66 FC 75, FC 85, FH 75, FS 75, FS 80, FS 85, HL 75, KM 85, KW 85
11. Special Sevicing Tools
No. Part Name Part No. Application Rem.
1 Locking strip 0000 893 5903 Blocking crankshaft
2 Puller 5910 890 4500 Removing limiter cap on carburetor
3 Torque wrench 5910 890 0301 0.5 to 18 Nm 1)2)
4 Torque wrench 5910 890 0311 6 to 80 Nm 1)3)
5 Socket, DIN 3124 SW 13 5910 893 5608 Flywheel nut
6 Socket, DIN 3124-S19x12.5L 5910 893 5613 Clutch
7 Socket, T 27 x 125 0812 542 2104 Installing and removing spline socket
head screws with electric or pneumatic
screwdrivers. Use torque wrench for
tightening
8 Fuel hose 1110 141 8600 Testing carburetor for leaks
9 Drift 4180 893 4400 Removing clutch drum
10 Drift 1108 893 4700 Removing and installing clutch drum
11 Hook 5910 890 2800 Detaching springs from clutch shoes
12 Hook 5910 893 8800 Removing pickup body, pulling plug out
of drive tube
13 Assembly stand 5910 890 3100 Mounting machine to workbench
14 Clamp 5910 890 8800 Holding FS units by drive tube for
repairs (in conjunction with assembly
stand)
15 Nipple 0000 855 9200 Testing carburetor for leaks
16 T-handle screwdriver, T 27x150 5910 890 2400 IS screws 4)
17 Vacuum pump 0000 850 3501 Testing crankcase for leaks, testing
tank vent
18 Carburetor and crankcase tester 1106 850 2905 Testing crankcase and carburetor for
leaks
19 Pliers, DIN 5254-A10 0816 610 1495 Removing and installing external
circlips
20 Press arbor 4119 893 7200 Installing plain bearing or needle
bearing in bearing housing
21 Service tool 4126 893 4900 Installing rubber element in AV sleeve
Remarks:
1) Always use torque wrench for tightening DG or P screws.
2) Alternative: Torque wrench 5910 890 0302 with optical/acoustic signal.
3) Alternative: Torque wrench 5910 890 0312 with optical/acoustic signal.
4) Only use for releasing/removing DG or P screws.
