Stihl RT 4082 User Manual

0478 193 9905 C - EN
102
Removing a wheel
Remove the cap (1). Remove the retaining
ring (2) using a screwdriver.
Pull the large washer (3) together with the
wheel (4) off the wheel axle.
Installing a wheel
The following points must be observed
before installing the wheels:
● Remove dirt from the wheel axle.
● Lightly coat the wheel axle with grease
before installation.
Insert feather key (5) in the rear wheel
axle. Push the wheel (4) with the large
washer (3) onto the wheel axle.
Allow retaining ring (2) to engage into the
groove on the wheel axle.
Fit cap (1) onto the wheel axle.
14.11 Opening and closing the storage
compartment
Opening the storage compartment:
● Stop the engine and allow it to cool
down. (Ö 12.3)
● Remove the ignition key and store
safely.
● Engage the parking brake. (Ö 8.10)
● Pull the driver's seat adjustment lever
upward and move the driver's seat to
the frontmost position (towards steering
wheel), or fold it forward.
Remove screws (1) by turning through 90°
anti-clockwise.
Fold storage compartment (2) up and
forward (toward driver's seat).
When removing the rear wheels,
ensure that the couplers (feather
keys) are not lost.
Before installing the rear wheels,
ensure that a coupler (feather key)
is located in the groove of the wheel
axle on both sides.

Stihl RT 4082 Specifications

General

Type	Walk behind lawn mower
Cutting width	800 mm
Grass catcher	Yes
Product color	Black, Grey, Orange
Turning radius	90 cm
Maximum lawn area	4000 m²
Fuel tank capacity	6 L
Vibration emission	3 m/s²
Engine displacement	452 cm³
Maximum cutting height	90 mm
Minimum cutting height	35 mm
Grass collecting volume	250 L
Power source	Gasoline

Weight and Dimensions

Depth	2130 mm
Weight	202000 g
