Stihl RT 4082 User Manual

77
DEFRNLITESPT EN
0478 193 9905 C - EN
Choke position:
Push throttle lever (1) fully forwards into
the choke position (note detent).
Setting the engine speed:
If throttle lever (1) is pushed forwards or
backwards, the engine speed changes
along with the speed of the mowing blade
if the mowing deck is engaged.
MAX position:
Maximum engine speed
MIN position:
Minimum engine speed
8.3 Mowing deck switch
The mowing deck switch can be used to
engage the mowing deck when the engine
is running and with due regard to all safety
devices (Ö 11.).
Engaging the mowing deck
Press switch (1) upwards to the stop.
Disengaging the mowing deck
Press switch (1) downwards to the stop.
8.4 Reverse mowing safety switch
The reverse mowing safety switch
enables the mowing deck for
mowing in reverse driving
direction. The mowing deck is
automatically disengaged for safety
reasons if reverse mowing is not enabled.
Set the throttle lever to the MAX
position during mowing and to start
the warm engine.
Avoid damage to the machine!
Do not engage the mowing blade in
tall grass or when set to the lowest
cutting level.
Only engage the mowing blade at
the maximum engine speed.
If necessary, the electronics can be
programmed so that the mowing
deck is automatically disengaged
when the grass catcher box is full.
(Ö 12.8)

Stihl RT 4082 Specifications

General

Type	Walk behind lawn mower
Cutting width	800 mm
Grass catcher	Yes
Product color	Black, Grey, Orange
Turning radius	90 cm
Maximum lawn area	4000 m²
Fuel tank capacity	6 L
Vibration emission	3 m/s²
Engine displacement	452 cm³
Maximum cutting height	90 mm
Minimum cutting height	35 mm
Grass collecting volume	250 L
Power source	Gasoline

Weight and Dimensions

Depth	2130 mm
Weight	202000 g
