Stihl RT 4082 User Manual

0478 193 9905 C - EN
108
● Reattach bolts, washers and nuts to the
battery negative (–) and positive (+)
terminals for safe keeping.
● Install the steering column cover if
necessary. (Ö 14.17)
Connecting the battery:
● Check the battery voltage before
installing the battery. If the minimum
voltage is not achieved, fully recharge
the battery using a battery charger
before installation.
Minimum voltage: 11,5 V
● Install the battery. (Ö 14.20)
● If necessary, remove the bolt, washer
and nut from the battery.
Attach the terminal connector of red
connection cable (4) to the battery
positive (+) terminal.
Tighten the connection cable with bolt (5),
washers (6), spring washer (8) and nut (7)
using two spanners (A/F8).
Tightening torque: 6 - 8 Nm
Fit cap (3) onto the bolt connection.
Attach the terminal connector of black
connection cable (2) to the battery
negative (–) terminal.
Tighten the connection cable with bolt (5),
washers (6), spring washer (8) and nut (7)
using two spanners (A/F8).
Tightening torque: 6 - 8 Nm
14.20 Removing and installing the
battery
Removing the battery:
● Remove the steering column cover.
(Ö 14.16)
● Disconnect the battery. (Ö 14.19)
Release retaining clasp (1) and remove
battery (2).
● Insert the retaining clasp.
● Install the steering column cover.
(Ö 14.17)
Installing the battery:
● Remove the steering column cover.
(Ö 14.16)
Fire hazard!
Always observe the specified
torque. Make sure that the bolt
connections at the terminals are
always tightened to avoid damage
due to sparking.

Stihl RT 4082 Specifications

General

Type	Walk behind lawn mower
Cutting width	800 mm
Grass catcher	Yes
Product color	Black, Grey, Orange
Turning radius	90 cm
Maximum lawn area	4000 m²
Fuel tank capacity	6 L
Vibration emission	3 m/s²
Engine displacement	452 cm³
Maximum cutting height	90 mm
Minimum cutting height	35 mm
Grass collecting volume	250 L
Power source	Gasoline

Weight and Dimensions

Depth	2130 mm
Weight	202000 g
